Kit components – Waterworks R.W. Atlas Deck Mounted Marquee Lavatory Faucet with Metal Lever Side Mount Handles User Manual
Page 7
5
W W W.WATERWORKS.COM
4
PRODUCT SUPPORT: 1 (800) 927-2120 (EXT 2)
*FINISH/COLOR MUST BE SPECIFIED WHEN ORDERING
++SUPPLIED AS A PAIR
STYLES: RWLS10
KIT COMPONENTS
KIT COMPONENTS
103699*
SPOU T
103696
MOUNTING HARDWARE
103614
TEE
103690
AER ATOR
O-RING
RUBBER WASHER
METAL WASHER
NUT
RUBBER WASHER
TEE
SPOUT
103700*
COUN TERCLOCKWISE
ON SIDEBODY
NUT
RUBBER WASHER
O-RING
103706
SUPPLY T UBE
103705
HOSE
103702
3/8" COUN TERCLOCKWISE
ON CARTRIDGE
SIDE BODY
SUPPLY TUBE
NUT
