Waterworks R.W. Atlas Deck Mounted Marquee Lavatory Faucet with Metal Lever Side Mount Handles - Manual (Page 3)

PRODUCT SUPPORT 800.927.2120 8am - 6pm EST
RW ATLAS
Marquee Three Hole Deck Mounted Lavatory Faucet
INSTALLATION GUIDELINES
Page 3 of 3 8.7.2012
These guidelines have been prepared for the professional contractor to aid in the installation of:
RW ATLAS MARQUEE DECK MOUNTED LAVATORY FAUCET WITH METAL SIDE MOUNT LEVER
HANDLES (STYLE# RWLS10)
All dimensions are based on original specification and are subject to change and variation.
Please consult your Design Associate for current specifications.
SEE SERVICE PART DOCUMENT FOR PART ORDERING, AVAILABLE ON WATERWORKS.COM
14. Inspect all connections for leaks.
15. Close the drain and fill the sink with water to make
sure the drain stopper and gasket operates and
seals properly.
16. Re-install the flow restricting aerator making sure
the washer is in place.
¾ The hex collars on the bottoms of the handle
assembly and the bottom of the spout assembly can
be rotated after installation to orientate the hexes so
they are straight.
¾ The handle barrels can also be rotated to the proper
orientation to align the "H" & "C".
¾ The screw on the top of the handle assembly and
on the top of the spout assembly are aesthetic and
does not serve any mechanical purposes and should
not be removed.
* Putty contains oils and can cause permanent
discoloration on certain materials such as marble,
granite and any porous surface.
¾ If further assistance is required, please contact
Product Support at 1-800-927-2120 (8am-6pm EST).
¾ See service part document for parts ordering,
available on WATERWORKS.COM.
