Pilz PNOZ s4 C 48-240VACDC 3 n/o 1 n/c - Manual (Page 24)

PNOZ s4
Operating Manual PNOZ s4
21396­EN­13 24
Times 751134 751184
Min. start pulse duration with a
monitored start
With rising edge 30 ms 30 ms
With falling edge 100 ms 100 ms
Supply interruption before de­ener­
gisation
20 ms 20 ms
Simultaneity, channel 1 and 2 ∞ ∞
Environmental data 751134 751184
Climatic suitability EN 60068­2­78 EN 60068­2­78
Ambient temperature
Temperature range ­10 ­ 55 °C ­25 ­ 55 °C
Storage temperature
Temperature range ­40 ­ 85 °C ­40 ­ 85 °C
EMC EN 60947­5­1, EN 61000­6­2, EN
61000­6­4 EN 60947­5­1, EN 61000­6­2, EN
61000­6­4
Vibration
In accordance with the standard EN 60068­2­6 EN 60068­2­6
Frequency 10,0 ­ 55,0 Hz 10,0 ­ 55,0 Hz
Amplitude 0,35 mm 0,35 mm
Airgap creepage
In accordance with the standard EN 60947­1 EN 60947­1
Overvoltage category III / II III / II
Pollution degree 2 2
Rated insulation voltage 250 V 250 V
Rated impulse withstand voltage 4,00 kV 4,00 kV
Protection type
Mounting area (e.g. control cab­
inet)
IP54 IP54
Housing IP40 IP40
Terminals IP20 IP20
Mechanical data 751134 751184
Mounting position Any Any
Mechanical life 10,000,000 cycles 10,000,000 cycles
Material
Bottom PC PC
Front PC PC
Top PC PC
Connection type Spring­loaded terminal Spring­loaded terminal
Mounting type plug­in plug­in
Conductor cross section with
spring­loaded terminals: Flexible
with/without crimp connector
0,20 ­ 2,50 mm², 24 ­ 12 AWG 0,20 ­ 2,50 mm², 24 ­ 12 AWG
Spring­loaded terminals: Terminal
points per connection
2 2
Stripping length 9 mm 9 mm
