PNOZ s4
Operating Manual PNOZ s4
21396­EN­13 22
Relay outputs 751134 751184
Utilisation category
In accordance with the standard EN 60947­4­1 EN 60947­4­1
Auxiliary contacts, AC1 at 240 V 240 V
Min. current 0,01 A 0,01 A
Max. current 6,0 A 6,0 A
Max. power 1500 VA 1500 VA
Auxiliary contacts, DC1 at 24 V 24 V
Min. current 0,01 A 0,01 A
Max. current 6,0 A 6,0 A
Max. power 150 W 150 W
Safety contacts, AC1 at 240 V 240 V
Max. current 6,0 A 6,0 A
Min. current 0,01 A 0,01 A
Max. power 1500 VA 1500 VA
Safety contacts, DC 1 at 24 V 24 V
Max. current 6,0 A 6,0 A
Min. current 0,01 A 0,01 A
Max. power 150 W 150 W
Utilisation category
In accordance with the standard EN 60947­5­1 EN 60947­5­1
Auxiliary contacts AC15 at 230 V 230 V
Max. current 3,0 A 5,0 A
Auxiliary contacts, DC13 (6
cycles/min) at
24 V 24 V
Max. current 4,0 A 5,0 A
Safety contacts, AC15 at 230 V 230 V
Max. current 3,0 A 5,0 A
Safety contacts DC13 (6 cycles/
min) at
24 V 24 V
Max. current 4,0 A 5,0 A
Contact fuse protection external,
safety contacts
In accordance with the standard EN 60947­5­1 EN 60947­5­1
Blow­out fuse, quick 6 A 10 A
Blow­out fuse, slow 4,00 A 6,00 A
Circuit breaker, 24V AC/DC,
characteristic B/C
4 A 6 A
Contact fuse protection external,
auxiliary contacts
Blow­out fuse, quick 6 A 10 A
Blow­out fuse, slow 4 A 6 A
Circuit breaker, 24 V AC/DC,
characteristic B/C
4 A 6 A
Contact material AgCuNi + 0,2 µm Au AgCuNi + 0,2 µm Au
