PNOZ s4
Operating Manual PNOZ s4
21396­EN­13 16
Electrical data 750104 750134 751104
Voltage at
Input circuit DC 24,0 V 24,0 V 24,0 V
Start circuit DC 24,0 V 24,0 V 24,0 V
Feedback loop DC 24,0 V 24,0 V 24,0 V
Current at
Input circuit DC 50,0 mA 50,0 mA 50,0 mA
Start circuit DC 50,0 mA 50,0 mA 50,0 mA
Feedback loop 50,0 mA 50,0 mA 50,0 mA
Number of output con­
tacts
Safety contacts (N/O),
instantaneous
3 3 3
Auxiliary contacts (N/C) 1 1 1
Inputs 750104 750134 751104
Number 2 2 2
Semiconductor outputs 750104 750134 751104
Number 1 1 1
Voltage 24,0 V 24,0 V 24,0 V
Current 20 mA 20 mA 20 mA
Relay outputs 750104 750134 751104
Max. short circuit current
IK
1 kA 1 kA 1 kA
Utilisation category
In accordance with the
standard
EN 60947­4­1 EN 60947­4­1 EN 60947­4­1
Auxiliary contacts, AC1
at
240 V 240 V 240 V
Min. current 0,01 A 0,01 A 0,01 A
Max. current 6,0 A 6,0 A 6,0 A
Max. power 1500 VA 1500 VA 1500 VA
Auxiliary contacts, DC1
at
24 V 24 V 24 V
Min. current 0,01 A 0,01 A 0,01 A
Max. current 6,0 A 6,0 A 6,0 A
Max. power 150 W 150 W 150 W
Safety contacts, AC1 at 240 V 240 V 240 V
Max. current 6,0 A 6,0 A 6,0 A
Min. current 0,01 A 0,01 A 0,01 A
Max. power 1500 VA 1500 VA 1500 VA
Safety contacts, DC 1
at
24 V 24 V 24 V
Max. current 6,0 A 6,0 A 6,0 A
Min. current 0,01 A 0,01 A 0,01 A
Max. power 150 W 150 W 150 W
