20 Menus, toolbars and screens Welch Allyn SmartLink Wireless
File menu
Open 12-Lead Transmission
The Open 12-Lead Transmission menu option is used to open a previously received
SmartLink Wireless data file with the .slw file extension.
The files are stored as shown below:
Exit
Selecting Exit shuts down the SmartLink Wireless software.
Tools menu
Options
The Options menu item displays the SmartLink Wireless Configuration dialog, from which
it is possible to configure mail settings, forwarding options, automation features, sounds,
and more.
Figure 5: IP addresses
As seen in “Figure 5: IP addresses” , the SmartLink Wireless software is required to have
a fixed IP address assigned to it. Contact your network administrator concerning the
assignment of the IP address. Your network administrator should assign the IP port
address for the SmartLink Wireless software to ensure that it does not conflict with any
SmartLink Wireless
software folder
eSync
Sender name or
PIC serial number
File name .slw
Directories
12-Lead files
PIC50 version
X3 or greater
PDA RS-232 cable
PDA
Wireless transmission
Cell tower
wireless provider
Internet
PC SmartLink Wireless
monitoring station or
Gateway
PDA IP address determined
by cellular provider
Data port
Control port
Monitoring
station or
Gateway IP
Must be a static
IP address
