1
Introduction
This manual describes the setup, installation, and use of the Image Capture System for Desktop
Computers, REF 88801 and Image Capture System for Notebook Computers, REF 88802.
Indications
The Welch Allyn Image Capture System is intended to capture, display, save, export, and print
images obtained from the Welch Allyn Video Colposcope. The images captured, displayed,
saved, exported, and printed from the Welch Allyn Image Capture System are not intended for
diagnostic purposes. The provider shall use the image on the colposcope monitor for clinical
diagnosis.
Unpacking Checklist (Welch Allyn Image Capture System only)
Welch Allyn Image Capture Software
Welch Allyn Image Capture Directions for Use Manual
DV Converter
IEEE 1394 Cable
S-Video Cable
RS-232 Serial Communications Cable (9-pin)
IEEE 1394 PCI or PCMCIA Card (if purchased)
Registration/Warranty Card
Installation Waiver form
Minimum System Requirements
Pentium/Celeron Family - 800 MHz
256MB RAM
Available IEEE 1394 Port
Available RS-232 Port (for communication with Video Colposcope buttons)
20GB Available Hard Drive Space for image storage
CD ROM drive (for software installation)
Monitor with 1024 x 768 Resolution, 256 Color Minimum
Windows
®
2000 or Windows
®
XP Operating System
*Verify your system has a dedicated IEEE 1394 port and a dedicated RS-232 port. The Image
Capture System does not support interfaces that reside on a hub, docking station, port replicator
or adapter (such as a USB to RS-232 adapter).
Symbols
Attention, consult Operator’s Manual for additional information
