29
.
Conducted RFI and Radiated RFI testing was performed on the EUT. Monitoring the output for
drops in voltage; none were detected.
Guidance and Manufacturer’s Declaration - Immunity
The Image Capture System is intended for use in the electromagnetic environment specified below. The
customer or user of the Image Capture System should ensure that it is used in such an environment
Immunity Test
IEC 60601
Test Level
Compliance
Level
Electromagnetic Environment -
Guidance
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
3 Vrms
150 kHz to
80MHz
3 V/m
80 MHz to 2.5
GHz
3 Vrms
3 V/m
Portable and mobile communications
equipment should be separated from the EUT
by no less than the distances calculated/listed
below:
D=0.35 (Sqrt P)
D=0.35 (Sqrt P)
80 to 800MHz
D=0.7 (Sqrt P)
800MHz to 2.5 GHz
Where P is the max power in watts and D is
the recommended separation distance in
meters.
Field strengths from fixed transmitters, as
determined by an electromagnetic site
survey, should be less than 10Vrms or 10V/m.
Interference may occur in the vicinity of
equipment containing a transmitter.
Recommended Separations Distances between portable and mobile RF
Communications equipment and the Welch Allyn Image Capture System
Guidance and Manufacturer’s Declaration - Emissions
The Image Capture System is intended for use in the electromagnetic environment in which radiated
disturbances are controlled. The customer or user of the Image Capture System can help prevent
electromagnetic interference by maintaining a minimum distance between portable and mobile RF
Communications Equipment and the Image Capture System as recommended below, according to the
maximum output power of the communications equipment.
Max Output
Power (Watts)
Separation (m)
150kHz to 80MHz
D=(3.5/V1) (Sprt P)
Separation (m)
80 to 800MHz
D=(3.5/E1) (Sprt P)
Separation (m)
800MHz to 2.5GHz
D=(7/E1) (Sprt P)
0.01 0.035 0.035 0.07
0.1 0.111 0.111 0.221
1 0.35 0.35 0.7
10 1.107 1.107 2.214
100 3.5 3.5 7.0
