FHR-35 Pan and Tilt Head Robotic
Safety and Warnings
installations, the teleprompter (if installed) is mounted on to the
head and protrudes the furthest beyond the base of the head.
The footprint must take into account the overhang of the
teleprompter and/or other payload equipment as the head
moves about the pan axis.
Personnel need to be trained and aware of how far the head
and pedestal can move, the speeds involved and the need to
stay clear of robotic equipment at all times.
Warning Signs
Warning signs should be displayed prominently in the
workplace alerting personnel that robotic equipment is in use
and may move suddenly without warning.
If personnel are working on robotic or associated equipment,
ensure a warning sign is placed at the controller (control panel)
to alert operators that work is being carried out.
Safety Notes for Operators
Each remote controlled head and/or pedestal in the system
should remain within the view of the operator at all times. Do
not operate a head and/or pedestal if it cannot be seen.
Before and during remote operation, the operator must verify
visually that the active area is clear of hazards and personnel. If
personnel are too close to a head or pedestal that is about to
move, the operator should prevent the motion from starting or
stop the motion after it has started.
Operators must familiarise themselves with the working
footprint of the robotic head, including all associated equipment
(lens, zoom and focus controls, viewfinder, prompter, etc.), to
prevent inadvertent collisions or injury to personnel.
Intended Use
This product is designed for use within television studios to
support and balance a camera together with ancillary
equipment weighing up to 16 kg (35 lb). Camera operators can
remotely control camera zoom and focus and movements about
the pan and tilt axes using Vinten Radamec control systems.
Safe Working Environment
In normal operation, remote controlled equipment can
move suddenly and without warning. Since audible warnings
are not suitable for use within the studio environment, it is
recommended that only trained personnel be allowed to work in
the active areas where remote controlled heads and pedestals
are located.
Personnel should be made aware of the potential hazards of
working in a robotic environment. To avoid personal injury,
personnel should always exercise caution when working in the
vicinity of robotic equipment. The forces are sufficient to cause
personal injury or injury to others and therefore caution is
essential.
Safe Operating Zone
The safe operating zone for personnel is a minimum of 1 m
(3 ft) outside of the footprint of the pan and tilt head. In most
3
Installation and Configuration Guide
CAUTION! Risk of damage to equipment. Do not lift or
carry the head by the top cover.
CAUTION! Do not use oil or grease on any exposed
part of the product. This is unnecessary and traps dirt
which acts as an abrasive.
