24
FHR-35 Pan and Tilt Head Robotic
ICE Tool
Installation and Configuration Guide There are two methods for setting the soft limits, depending on
the accessibility of the mounting installation.
Accessible (or Manual) Mounting
Move the pan mechanism to the required minimum
R
Click Apply to send and store the settings in the head.
1.
3.
4.
position
and click the Set Min button to store the value.
2. Move the pan mechanism to the required maximum position
and click the Set Max button.
epeat steps 1 and 2 to set the tilt axis minimum and
maximum limits.
Inaccessible Mounting (Wall or Ceiling)
Enter a minimum
Enter a maximum
Click Apply to send and store the settings in the head.
1.
3.
soft limit value in the pan and tilt Min
Limits boxes and click the Set Min button to store the value.
2. soft limit value in the pan and tilt Max
Limits boxes and click the Set Max button.
Setting the pan and tilt soft limits
CAUTION! Risk of product damage. Soft limits must be
set inside the range set for the hard limits.
Soft Limits
Setting the zoom and focus soft limits
Minimum and maximum soft limits can also be set for the lens
focus and zoom. Units represent 0–100% of the full range for
each setting.
1. Set the lens to the required minimum zoom setting and click
the Set Min button to store the value.
2. Set the lens to the required maximum zoom setting and click
the Set Max button to store the value.
3. Repeat steps 1 and 2 to set limits for the focus.
4. Click Apply to send and store the settings in the head.
