FHR-35 Pan and Tilt Head Robotic
General Notices
28
Mounting supports and adaptors
Vinten 4-bolt adaptor (with Quickfix® groove) . . . . V4096-1013
. . . . . . . . . . . . . . . . . .
Vinten 4-bolt to 150 mm bowl adaptor . . . . . . . . . . . . . . . 3104-3
Vinten Quickfix 150 mm bowl adaptor . . . . . . . . . . . . . . 3143-3
Vinten HD Quickfix adaptor . . . . . . . . . . . . . . . . . . . . . . 3490-3
. .
. . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . .
VMA plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AM-VMA-105
Radamec adaptor column
196-728-0044
Autocam ceiling mounting bracket. . . . . . . . . . . . . AM-CEIL-102
Autocam wall mounting bracket . . . . . . . . . . . . . AM-WBKT-102
®
®
User-replaceable parts
Mounting kit
(incl. cable management brackets) . . . . . . . . . . . . . V4096-1905
Vinten two-stage aluminium EFP Pozi Loc tripod V4086-0001
Vinten two-stage carbon fibre EFP Pozi Loc tripod 3881-3
Vinten HDT-1 single-stage tripod 3901-3
Vinten HDT-2 two-stage tripod 3902-3
Physical data
Weight (with cradle) . . . . . . . . . . . . . . . . . . . . . . . . . 8 kg (18 lb)
Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247.4 mm (9.7 in.)
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323.5 mm (12.7 in.)
Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193.5 mm (7.6 in.)
Maximum payload . . . . . . . . . . . . . . . . . . . . . . . . . 16 kg (35 lb)
Operating data
Operating temperature range . . 0°C to +50°C (+32°F to +122°F)
Motor noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Minimal
Tilt range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±90°
Pan range, max. (with mechanical end stops set) . . . . . . . 319°
Angular velocity (max) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60°/s
2 Angular acceleration (typical) . . . . . . . . . . . . . . . . . . . . . . 60°/s
2 Angular acceleration (peak) . . . . . . . . . . . . . . . . . . . . . . 120°/s
Accuracy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 arcseconds
Robotic operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Full
Manual operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . None
Electrical data
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100W
Power input . . . . . . . . . . . Autoranging 100–240V AC, 50/60 Hz
Specification Parts List
Installation and Configuration Guide
