Counterpart User Manual - For More Information 69
STR.GROSS
STR.NET
STR.TARE Mode. Specifies gross, net, or tare weight for the current or
specified weight on the source scale.
STR.MOTION
STR.RANGE
STR.OK
STR.INVALID Status for the source scale. Default values and meanings for each
status:
STR.MOTIONMIn motion
STR.RANGEOOut of range
STR.OKOK
STR.INVALIDIInvalid
— Status of over/under/accept. O=Over, U=Under, A=Accept.
See descriptions below Bit fields. Comma-separated sequence of bit field specifiers. Must
be exactly 8 bits. Minus sign ([–]) inverts the bit.
B0 — Always 0
B1 — Always 1
B2 Configuration =1 if even parity
B3 Dynamic =1 if MODE=NET
B4 Dynamic =1 if COZ
B5 Dynamic =1 if standstill
B6 Dynamic =1 if gross negative
B7 Dynamic =1 if out of range
B8 Dynamic =1 if secondary/tertiary
B9 Dynamic =1 if tare in system
B10 Dynamic =1 if tare is keyed
B11 Dynamic =00 if MODE=GROSS
=01 if MODE=NET
=10 if MODE=TARE
=11 (not used)
B12 Dynamic =00 if UNITS=PRIMARY
=01 if UNITS=SECONDARY
=10 if UNITS=TERTIARY
=11 (not used)
B13 Configuration =00 (not used)
=01 if current DSPDIV=1
=10 if current DSPDIV=2
=11 if current DSPDIV=5
B14 Configuration =00 (not used)
=01 if primary DSPDIV=1
=10 if primary DSPDIV=2
=11 if primary DSPDIV=5
B15 Configuration =00 (not used)
=01 if secondary DSPDIV=1
=10 if secondary DSPDIV=2
=11 if secondary DSPDIV=5
B16 Configuration =00 (not used)
=01 if tertiary DSPDIV=1
=10 if tertiary DSPDIV=2
=11 if tertiary DSPDIV=5
Format Identifier Defined By Description
Table 9-3. Custom Stream Formatting
