INSTALLATION TYPES
Mullion end anchor
Mullion mid−point anchor
(deadload)
Mullion mid−point anchor
(expansion)
Mullion splice
Mullion end anchor
Mullion end anchor
Mullion end anchor
Mullion mid−point anchor
at Twin Span Installations
Single Span & Twin Span
Refer to steps 2.1.1 through 2.1.5
Multi−Span
Refer to steps 2.1.6 through 2.1.13
The following wall sections represent common types of installations for this product.
Refer to approved shop drawings for specifics regarding splicing and anchoring of frame.
