Oldcastle BuildingEnvelope Reliance-HTC - Manual (Page 10)

AW-375 @ 1 3/4" glazing
AW-385 @ 2" glazing
(top & bottom of mullion) AW-370 @ 1 3/4" glazing
AW-380 @ 2" glazing
(top & bottom of mullion)
A
A
A
B
B
B
C
C
C
A
A
A
B
B
B
C
C
C
DJ-113
drill jig
SSG Vertical Captured Vertical
AW-181-01 @ 7 1/4", 7 1/2" depths
AW-182-01 @ 10", 10 1/4" depths
Top of horizontal
3/4
"
1 1
/4"
1 3
/4"
3"
1 3
/8"
3/4
"
See approved shop
drawings for number
of screws required
#11 (.191 dia) hole
for 1/4" fastener
FS-9 (typ.)
FIGURE 2
Vertical Fabrication
FRAME FABRICATION
FS-320 #10 x 1/2" U-drive
R E L I A N C E − H T C I N S T A L L A T I O N M A N U A L
MAY 2013 7
