7.3 I/O Address Map
The I/O-port addresses of the ETXexpress®-AI COM are functionally identical
to those of a standard PC/AT system, so any addresses not mentioned in Table
22 should also be available. All addresses are fixed I/O ranges that are
decoded by the PCH used in this module.
Table 22: I/O Address Assignments
I/O
Address
Read Target Write Target Internal
Unit
00h-08h DMA Controller DMA Controller DMA
09h-oEh Reserved DMA Controller DMA
0Fh DMA Controller DMA Controller DMA
10h-18h DMA Controller DMA Controller DMA
19h-1Eh Reserved DMA Controller DMA
1Fh DMA Controller DMA Controller DMA
20h-21h Interrupt
Controller Interrupt
Controller Interrupt
24h-25h Interrupt
Controller Interrupt
Controller Interrupt
28h-29h Interrupt
Controller Interrupt
Controller Interrupt
2Ch-2Dh Interrupt
Controller Interrupt
Controller Interrupt
2E-2F LPC SIO LPC SIO Forwarded
to LPC
30h-31h Interrupt
Controller Interrupt
Controller Interrupt
34h-35h Interrupt
Controller Interrupt
Controller Interrupt
38h-39h Interrupt
Controller Interrupt
Controller Interrupt
3Ch-3Dh Interrupt
Controller Interrupt
Controller Interrupt
40h-42h Timer/Counter Timer/Counter PIT (8254)
43h Reserved Timer/Counter PIT
4E-4F LPC SIO LPC SIO Forwarded
to LPC
50h-52h Timer/Counter Timer/Counter PIT
53h Reserved Timer/Counter PIT
60h Microcontroller Microcontroller Forwarded
to LPC
61h NMI Controller NMI Controller Processor
I/F
62h Microcontroller Microcontroller Forwarded
to LPC
64h Microcontroller Microcontroller Forwarded
to LPC
–66h Microcontroller Microcontroller Forwarded
to LPC
