Kontron ETXexpress-AI User’s Guide
52
Pin Signal Description Type Terminatio
n
Comment
D99 PEG_TX14- PCI Express
Graphics
Transmit Data
Lane 14
Negative DP-O
D100 GND (Fixed) Power Ground PWR - -
D101 PEG_TX15+ PCI Express
Graphics
Transmit Data
Lane 15
Positive DP-O
D102 PEG_TX15- PCI Express
Graphics
Transmit Data
Lane 15
Negative DP-O
D103 GND Power Ground PWR - -
D104 VCC_12V 12V VCC PWR - -
D105 VCC_12V 12V VCC PWR - -
D106 VCC_12V 12V VCC PWR - -
D107 VCC_12V 12V VCC PWR - -
D108 VCC_12V 12V VCC PWR - -
D109 VCC_12V 12V VCC PWR - -
D110 GND (Fixed) Power Ground PWR - -
NOTE: The termination resistors in this table are already mounted on the
ETXexpress® board. Refer to the PICMG COM Express™ Design Guide for
information about additional termination resistors.
