Storage

SATA:

4xSerial ATA (SATA) ports
supports up to 1.5 Gbit/sec transfer rate SATA-to-PATA
bridge (Type 2 only)

SATA Features: Boot, RAID0, RAID1, NCQ, Staggered Spinup, Port Multiplier

IDE/PATA

1x Parallel ATA (PATA) port (Type 2 only)

Onboard Devices:

Ethernet:

Intel® 82577LM PHY (Max TDP 0.727W) uses one PCIe lane

Ethernet Features:

WakeOnLAN, PXE Lanboot, Time Sync Protocol Indicator,

Jumbo Frames

TPM:

Atmel AT97SC3203-X9M10 Trusted Platform Module 1.2, onboard
(build option)

Watchdog Timer: Kontron PIC microcontroller (interfaces to chipset

over a watchdog-specific I

C interface)

PCI:

32-bit/33 MHz PCI 2.3 (Type 2 only)

Power Management:

L0-L3, Device Power Management (D0-D3 hot)

AMT

AMT 6.0 Active Management Technology

Optional:

1xPATA HDD interface (Type 2 only)

Additional Interfaces:

LPC bus:

Yes, to COM Express A-B connector

SMBus:

Yes, to COM Express A-B connector

C: Fast

C from CPLD

GPIO:

8xGPIO, 4 GPI and 4 GPO from PCH

SPI

Yes, to COM Express A-B connector

JIDA:

AMI Aptio 4.6.3.5 Core UEFI BIOS

K-Station:

Yes

Bootlogo: Yes

MARS:

Yes, Charger & Manager Support

HWM:

Temperature Monitoring for CPU and Board Temperature

Passive Cooling: Passive and Critical Trip Point

ACPI:

ACPI 1.0 / 2.0 / 3.0 with S5 Eco

S-States:

S0, S3, S4, S5

Input Voltage: Single supply support with wide range power supply input,

8V – 18V
