Kontron ETXexpress-AI User’s Guide
18
Pin Signal Description Type Terminatio
n
Comment
A83 LVDS_I2C_CK LVDS I 2 C Clock IO-3.3
A84 LVDS_I2C_DA
T LVDS I 2 C Data IO-3.3
A85 GPI3 General Purpose Input
3 I-3.3
A86 KBD_RST# Keyboard Reset I-3.3
A87 KBD_A20GATE A20 gate I-3.3
A88 PCIE0_CK_RE
F+ PCIe Clock (positive) DP-O
A89 PCIE0_CK_RE
F- PCIe Clock (negative) DP-O
A90 GND (Fixed) Power Ground PWR - -
A91 SPI_Power Power for off-board
SPI flash O-3.3
A92 SPI_MISO SPI Master In Slave
Out data line I-3.3
A93 GPO0 General Purpose
Output 0 O-3.3
A94 SPI_CLK SPI clock line for
off-board SPI O-3.3
A95 SPI_MOSI SPI Master Out Slave
In data line O-3.3 -
A96 GND Power Ground PWR - -
A97 TYPE10# Not
connected nc nc
A98 RSVD Reserved Not
connected nc nc
A99 RSVD Reserved Not
connected nc nc
A100 GND (Fixed) Power Ground PWR - -
A101 RSVD Reserved Not
connected nc nc
A102 RSVD Reserved Not
connected nc nc
A103 RSVD Reserved Not
connected nc nc
A104 VCC_12V 12V VCC PWR - -
A105 VCC_12V 12V VCC PWR - -
A106 VCC_12V 12V VCC PWR - -
A107 VCC_12V 12V VCC PWR - -
A108 VCC_12V 12V VCC PWR - -
A109 VCC_12V 12V VCC PWR - -
A110 GND Power Ground PWR - -
