Kontron ETXexpress-AI User’s Guide
107
High
Definition
Audio Disabled
Enabled
Auto Enable/disable HAD docking
support for the audio
controller
Disabled = HAD is
unconditionally disabled
Enabled = HAD is
unconditionally enabled
Auto = HAD is enabled if
present, and disabled if not
HDA Docking
Support Disabled
Enabled
Enable/disable HAD Docking
Support of Audio Controller
HAD PME
Enable Disabled
Enabled
Enable/disable Power
Management capability of
Audio Controller.
HDA Internal
HDMI codec Disabled
Enabled
Enable/disable internal HDMI
codec for HDA
Display
logic Disabled
Enabled
Enable/disable the PCH
Display logic
CLKRUN#
logic Disabled
Enabled Enable/disable the CLKRUN#
logic to stop the PCI clocks
High
Precision
Timer Disabled
Enabled Enable /disable the High
Precision Event Timer
Boot Time
with HPET
Timer Disabled
Enabled
Enable/disable Boot time
calculation with High
Precision Event Timer
Clock Spread
Spectrum Disabled
Enabled
Enable/disable Clock chi
Spread Spectrum feature
State After
G3 Power On State
Power Off State
Last State Specify what state to go to
when power is re-applied
after a power failure (G3
state)
Set NAND
Management
Overrride Disabled
Enabled Option to override NAND
management to allow driver or
3rd party software to
configure the NAND module
after POST
