Kontron ETXexpress-AI User’s Guide

PCI Express:

6xPCIe x1 lanes on Type 2, 7xPCIe x1 lanes on Type 6
1xPCIe Gen 2 graphics (PEG) x16 or configurable as 2xPCIe
x8 (Type 6)
(2x PCIe x8 on Type 2 also as a custom stuffing option)

PCI

PCI Rev 2.3 @ 32/33 MHz (Type 2 only, not supported on Type
6)

Package:

37.5mm x 37.5mm

Integrated Graphics: Intel® Graphics Media Accelerator
4500(Intel® GMA 4500)

The integrated graphics controller contains a refresh of the 5th generation

graphics core.

Features:

Intel® Dynamic Video Memory Technology support

Intel® Smart 2D Display Technology (Intel® S2DDT)

Intel® Clear Video Technology:
— MPEG2 Hardware Acceleration
— WMV9/VC1 Hardware Acceleration
— AVC Hardware Acceleration
— ProcAmp
— Advanced Pixel Adaptive De-interlacing
— Sharpness Enhancement
— De-noise Filter
— High Quality Scaling
— Film Mode Detection (3:2 pull-down) and Correction
— Intel® TV Wizard

12 EUs

Dedicated analog and digital display ports supported through the PCH

Display Interfaces

CRT:

Resolution up to QXGA (2048x1536)
Resolution up to 1400x1050 analog VGA

Flat Panel:

Dual channel LVDS 24bpp,
resolution up to 1366 x 768 (WXGA), no dithering
or analog VGA

Digital Display: SDVO/DP/DVI/HDMI (Type 6 only)
