Pin Signal Description Type Termination Comment
Data-
A54 GPI0 General Purpose
Input 0 I-3.3
A55 PCIE_TX4+ PCIe 4 Transmit
Data+ DP-O
A56 PCIE_TX4- PCIe 4 Transmit
Data- DP-O
A57 GND (Fixed) Power Ground PWR - -
A58 PCIE_TX3+ PCIe 3 Transmit
Data+ DP-O
A59 PCIE_TX3- PCIe 3 Transmit
Data- DP-O
A60 GND (Fixed) Power Ground PWR - -
A61 PCIE_TX2+ PCIe 2 Transmit
Data+ DP-O
A62 PCIE_TX2- PCIe 2 Transmit
Data- DP-O
A63 GPI1 General Purpose
Input 1 I-3.3
A64 PCIE_TX1+ PCIe 1 Transmit
Data+ DP-O
A65 PCIE_TX1- PCIe 1 Transmit
Data- DP-O
A66 GND (Fixed) Power Ground PWR - -
A67 GPI2 General Purpose
Input 2 I-3.3
A68 PCIE_TX0+ PCIe lane #0
Transmit+ DP-O
A69 PCIE_TX0- PCIe lane #0
Transmit- DP-O
A70 GND (Fixed) Power Ground PWR - -
A71 LVDS_A0+ LVDS Channel A
(positive) DP-O
A72 LVDS_A0- LVDS Channel A
(negative) DP-O -
A73 LVDS_A1+ LVDS Channel A
(positive) DP-O -
A74 LVDS_A1- LVDS Channel A
(negative) DP-O
A75 LVDS_A2+ LVDS Channel A
(positive) DP-O
A76 LVDS_A2- LVDS Channel A
(negative) DP-O
A77 LVDS_VDD_EN LVDS Panel Power
Controller O-3.3
A78 LVDS_A3+ LVDS Channel A
(positive) DP-O
A79 LVDS_A3- LVDS Channel A
(negative) DP-O
