Kontron ETXexpress-AI User’s Guide

Specifications

3.1

Functional Specification

Processor: Intel® Core™ i7 and Core™ i5

CPU:

Intel® Core™ i7-620UE (1.06 GHz)
Intel® Core™ i7-620LE (2.00 GHz)
Intel® Core™ i5-520E (2.40 GHz)
Intel® Core™ i7-610E (2.53.GHz)
Intel® Celeron® P4505 (1.86 GHz)

Cores:

2 (with HTT)

Bus Speed:

800/1066 FSB

Bus/Core Ratio: 11/12

Cache:

L1 cache 24KB data/32 KB instruction
L2 cache up to 4 MBytes, 8-way

Memory:

2xDDR3 800/1600 MHz SODIMM sockets, up to 8 GBytes, with
ECC support
Additional SKUs for modules supporting non-ECC memory

Graphics

PCIe x16 graphics (or 2 x8)
can also be used for an embedded DisplayPort (eDP)

Features:

Hyper-Threading Technology (HTT)

Intel® Virtualization Technology

Execute Disable Bit

Enhanced Intel® Speedstep Technology

Core Sleep States: C0, C1E, C2E, C3, C4E, Intel Deep Power
Down State C6

Instruction Set:

32-bit

Package:

22mm x 22mm

Thermal Spec:

Operation: 0° to 60°C
Storage: -30° to 85°

NOTE: Intel Deep Power Down State C6 may not be available in the first early

field test (EFT) samples.

Chipset: Mobile Intel® QM57 Platform Controller Hub (PCH)

Speed: 800/1066

FSB

USB:

8xUSB 2.0 One USB port with debug capability is mapped to
USB Port 0. (This is a new requirement in COM.0 Rev. 2)

Audio:

Intel® High Definition Audio (24 bit/96 kHz)
