Kontron ETXexpress-AI User’s Guide
49
Pin Signal Description Type Terminatio
n
Comment
Transmit Data
Lane 0 Positive
D53 PEG_TX0- PCI Express
Graphics
Transmit Data
Lane 0 Negative DP-O
D54 PEG_LANE_RV# PCI Express
Graphics Lane
Reversal Input
strap I-3.3
D55 PEG_TX1+ PCI Express
Graphics
Transmit Data
Lane 1 Positive DP-O
D56 PEG_TX1- PCI Express
Graphics
Transmit Data
Lane 1 Negative DP-O
D57 TYPE2# Not connected –
for Type 2
modules Not Connected nc nc
D58 PEG_TX2+ PCI Express
Graphics
Transmit Data
Lane 2 Positive DP-O
D59 PEG_TX2- PCI Express
Graphics
Transmit Data
Lane 2 Negative DP-O
D60 GND (Fixed) Power Ground PWR - -
D61 PEG_TX3+ PCI Express
Graphics
Transmit Data
Lane 3 Positive DP-O
D62 PEG_TX3- PCI Express
Graphics
Transmit Data
Lane 3 Negative DP-O
D63 RSVD Reserved Not connected nc nc
D64 RSVD Reserved Not connected nc nc
D65 PEG_TX4+ PCI Express
Graphics
Transmit Data
Lane 4 Positive DP-O
D66 PEG_TX4- PCI Express
Graphics
Transmit Data
Lane 4 Negative DP-O
D67 GND Power Ground PWR - -
