Pin Signal Description Type Termination Comment
A103 LID# LID Button I/OP-3.3
A104 VCC_12V 12V VCC PWR - -
A105 VCC_12V 12V VCC PWR - -
A106 VCC_12V 12V VCC PWR - -
A107 VCC_12V 12V VCC PWR - -
A108 VCC_12V 12V VCC PWR - -
A109 VCC_12V 12V VCC PWR - -
A110 GND Power Ground PWR - -
Table 8: Type 6 Connector X1A - Row B
Pin Signal Description Type Termination Comment
B1 GND (Fixed) Power Ground PWR - -
B2 GBE0_ACT# Ethernet Activity
LED Not connected nc nc
B3 LPC_FRAME# LPC Frame
Indicator O-3.3
B4 LPC_AD0 LPC Address/Data
Bus IO-3.3
B5 LPC_AD1 LPC Address/Data
Bus IO-3.3
B6 LPC_AD2 LPC Address/Data
Bus IO-3.3
B7 LPC_AD3 LPC Address/Data
Bus IO-3.3
B8 LPC_DRQ0# LPC Serial DMA
Request I-3.3
B9 LPC_DRQ1# LPC Serial DMA
Request I-3.3
B10 LPC_CLK LPC Clock O-3.3
B11 GND (Fixed) Power Ground PWR - -
B12 PWRBTN# Power Button Input I-3.3
B13 SMB_CLK SMBus Clock O-3.3
B14 SMB_DAT SMBus Data IO-3.3
B15 SMB_ALERT# SMBus Interrupt IO-3.3
B16 SATA1_TX+ SATA 1 Transmit
Data+ DP-O
B17 SATA1_TX- SATA 1 Transmit
Data- DP-O
B18 SUS_STAT# Imminent suspend
operation; used to
notify LPC
devices. O-3.3
B19 SATA1_RX+ SATA 1 Receive
Data+ DP-I
B20 SATA1_RX- SATA 1 Receive
Data- DP-I
B21 GND (Fixed) Power Ground PWR - -
