Kontron ETXexpress-AI User’s Guide
48
Pin Signal Description Type Terminatio
n
Comment
D26 DDI1_PAIR0+ Digital Display
Interface DP-O
D27 DDI1_PAIR0- Digital Display
Interface DP-O
D28 RSVD Reserved Not connected nc nc
D29 DDI1_PAIR1+ Digital Display
Interface1+ DP-O
D30 DDI1_PAIR1- Digital Display
Interface1- DP-O
D31 GND (FIXED) Power Ground PWR - -
D32 DDI1_PAIR2+ Digital Display
Interface2+ DP-O
D33 DDI1_PAIR2- Digital Display
Interface2- DP-O
D34 DDI1_DDC_AUX_S
EL Selects
function of DDI
CRTL & DATA Aux I-3.3
D35 RSVD Reserved
D36 DDI1_PAIR3+ Digital Display
Interface3+ DP-O
D37 DDI1_PAIR3- Digital Display
Interface3- DP-O
D38 RSVD Reserved - - -
D39 DDI2_PAIR0+ Digital Display
Interface0+ DP-O
D40 DDI2_PAIR0- Digital Display
Interface0- DP-O
D41 GND (FIXED) Power Ground PWR - -
D42 DDI2_PAIR1+ Digital Display
Interface1+ DP-O
D43 DDI2_PAIR1- Digital Display
Interface1- DP-O
D44 DDI2_HPD Digital Display
Interface Hot-
Plug Detect I-3.3
D45 RSVD Reserved Not connected nc nc
D46 DDI2_PAIR2+ Digital Display
Interface2+ DP-O
D47 DDI2_PAIR2- Digital Display
Interface2- DP-O
D48 RSVD Reserved Not connected nc nc
D49 DDI2_PAIR3+ Digital Display
Interface3+ DP-O
D50 DDI2_PAIR3- Digital Display
Interface3- DP-O
D51 GND (Fixed) Power Ground PWR - -
D52 PEG_TX0+ PCI Express
Graphics DP-O
