Kontron ETXexpress-AI User’s Guide
104
Features Options Description
DVMT Pre-
Allocated 32M
64M
128M
Select DVMT 5.0 Pre-Allocated
(fixed) Graphics Memory size
used by the Internal Graphics
Device (IGD)
DVMT Total
Gfx Memory 128M
256M
MAX
Select DVMT 5.0 Total Graphic
Memory size used by the
Internal Graphics Device
(IGD)
Render
Standby Disabled
Enabled Enable/disable render standby
support.
IGD – Boot
Type VBIOS Default
CRT
LFP
CRT + LFP
LFP-SDVO
EFP2
EFP3
EFP
CRT + LFP-SDVO
CRT + EFP
Select the video device to be
activated during POST. This
has no effect if external
graphics present.
LCD Panel
Type VBIOS Default
800x600 LVDS
1024x768 LVDS
1280x1024 LVDS
…
…
…
2040x1536 LVDS
Select LCD panel used by
Internal Graphics Device by
selecting the appropriate
setup item
Panel
Scaling Auto
Force Scaling
Off
Maintain Aspect Ratio
Select the LCD panel scaling
option used by the Internal
Graphics Device (IGD)
Backlight
Control PWM Inverted
PWM Normal
GMBus Inverted
GMBus Normal
Backlight control setting
BIA Auto
Disabled
Level 1
Level 2
Level 3
Level 4
Level 5
Auto: GMCH Use VBT default;
Level n” Enable with Selected
Aggressiveness Level.
TV1 Standard VBIOS Default
TV2 Standard VBIOS Default
ALS Support Enabled
Disabled Valid only for ACPI
Legacy = ALS Support through
the IGD INIT10 function
ACPI = ALS support through an
ACPI ALS driver
