Kontron ETXexpress-AI User’s Guide
41
NOTE: The termination resistors in this table are already mounted on the
ETXexpress® board. Refer to the PICMG COM Express™ Design Guide for
information about additional termination resistors.
Table 9: Type 6 Connector X1B - Row C
Pin
Signal
Description
Type
Terminatio
n
Comment
C1
GND (Fixed)
Power Ground
PWR
-
-
C2
GND
Power Ground
PWR
-
-
C3
USB_SSRXO-
SuperSpeed USB
Data Receive
Path 0-
Not connected
nc
nc
C4
USB_SSRXO+
SuperSpeed USB
Data Receive
Path 0+
Not connected
nc
nc
C5
GND
Power Ground
PWR
-
-
C6
USB_SSRX1-
SuperSpeed USB
Data Receive
Path 1-
Not connected
nc
nc
C7
USB_SSRX1+
SuperSpeed USB
Data Receive
Path 1+
Not connected
nc
nc
C8
GND
Power Ground
PWR
-
-
C9
USB_SSRX2-
SuperSpeed USB
Data Receive
Path 2-
Not connected
nc
nc
C10
SUB_SSRX2+
SuperSpeed USB
Data Receive
Path 2+
Not connected
nc
nc
C11
GND (Fixed)
Power Ground
PWR
C12
USB_SSRX3-
SuperSpeed USB
Data Receive
Path 3-
Not connected
nc
nc
C13
USB_SSRX3+
SuperSpeed USB
Data Receive
Path 3+
Not connected
nc
nc
C14
GND
Power Ground
PWR
-
-
C15
DDI1_PAIR6+
Digital
Display
Interface
Not connected
nc
nc
C16
DDI1_PAIR6-
Digital
Display
Interface
Not connected
nc
nc
C17
RSVD
Reserved
Not connected
nc
nc
C18
RSVD
Reserved
Not connected
nc
nc
C19
PCIE_RX6+
PCI Express
Differential
Receive Pair
6+
DP-I
