Pin Signal Description Type Termination Comment
Data+
B53 PCIE_RX5- PCIe 5 Receive
Data- DP-I
B54 GPO1 General Purpose
Output 1 O-3.3
B55 PCIE_RX4+ PCIe 4 Receive
Data+ DP-I
B56 PCIE_RX4- PCIe 4 Receive
Data- DP-I
B57 GPO2 General Purpose
Output 2 O-3.3
B58 PCIE_RX3+ PCIe 3 Receive
Data+ DP-I
B59 PCIE_RX3- PCIe 5 Receive
Data- DP-I
B60 GND (Fixed) Power Ground PWR - -
B61 PCIE_RX2+ PCIe 2 Receive
Data+ DP-I
B62 PCIE_RX2- PCIe 2 Receive
Data- DP-I
B63 GPO3 General Purpose
Output 3 O-3.3
B64 PCIE_RX1+ PCIe 1 Receive
Data+ DP-I
B65 PCIE_RX1- PCIe 1 Receive
Data- DP-I
B66 WAKE0# PCI Express Wake
Event I-3.3
B67 WAKE1# General Purpose
Wake Event I-3.3
B68 PCIE_RX0+ PCIe lane #0
Receive+ DP-I
B69 PCIE_RX0- PCIe lane #0
Receive- DP-I
B70 GND (Fixed) Power Ground PWR - -
B71 LVDS_B0+ LVDS Channel B0
(Positive) DP-O
B72 LVDS_B0- LVDS Channel B0
(Negative) DP-O
B73 LVDS_B1+ LVDS Channel B1
(Positive) DP-O
B74 LVDS_B1- LVDS Channel B1
(Negative) DP-O
B75 LVDS_B2+ LVDS Channel B2
(Positive) DP-O
B76 LVDS_B2- LVDS Channel B2
(Negative) DP-O
B77 LVDS_B3+ LVDS Channel B3
(Positive) DP-O
B78 LVDS_B3- LVDS Channel B3 DP-O
