Menus | 29
7.0 Menus
Menus allow you to customize the settings for your particular requirements. The
menus are listed at the bottom of the screen and can be accessed by pressing
the function keys directly below the display.
There are three menus available from both the monitoring and logging screen:
MAIN, CONFIG, and STATUS.
MAIN Menu
From the MAIN menu you may view
the type of probe attached to the
HI-4460 Graphical Readout, select a
probe if one is not attached, choose
the display rate, and select the axis
to monitor.
• To move up or down the list, press the up or down MODE key.
• To select an item, press the SCREEN/SELECT key.
• To change the values, press the up or down MODE key again.
• To save the setting, press the BACK/ENTER key.
• To back out without changing the item, press the ESC/CLR key. The new
settings are saved when the menu is exited.
• To exit the menu and save all new settings, press the BACK/ENTER key.
• To exit the menu and cancel all setting changes, press the ESC/CLR key.
Archived 4/2/10
