7

NO-RUST WEATHER LAST™

WALL SLEEVE AND FRONT

PANEL

The indoor front panel and polymer wall sleeve use

nonmetallic compounds that never rust or corrode, do

not support combustion, and do not give off toxic

fumes. The weather-resistant feature exceeds require-

ments of Underwriters Laboratories and resists dam-

age caused by impact and scratching. The Weather

Last feature also insulates and has up to 10 times the

acoustic absorption of metal cabinets.
Insulated polymer wall sleeves combine all of the

above features with factory-installed insulation. The

insulation helps to reduce heat loss, save energy, pro-

vide better sound absorption, and reduce the risk of

sleeve sweating.
Carrier’s metal wall sleeves are available in a variety

of sizes for most standard and deep wall applications.

All metal wall sleeves come with factory-installed

insulation, designed to minimize heat loss and reduce

outdoor noise transmissions into the room.

REMOVABLE FRONT PANEL

The louvered front panel fits firmly onto the chassis

and features easy removal for service. It provides front

air intake to enhance performance and quiet operation.

It also allows the option of flush mounting PTAC unit

to the floor. If desired, the front panel can be

secured to the unit with field-supplied screws.

The

2 locking screws (if installed) are located behind the

removable filter handles.

ANTI-THEFT KNOBS

The anti-theft knobs are captured underneath the front

panel of the unit to prevent the knobs from being

removed or stolen.

REMOVABLE
FILTER

LOCATION OF
REMOVED FILTER

LOCKING SCREW
(NOTE: 2nd LOCKING SCREW
IS LOCATED BEHIND
2nd FILTER)

42 in.

16 in.

14/18/24/26/28 in

TEMPERATURE

MODE

OFF

LO

HI

COOL

FAN

HI

HEAT

COOLER

WARMER

LO

Removable Front Panel

Standard Wall Sleeve (Polymer)

Standard and Deep Wall Sleeve (Metal)

Anti-Theft Knobs
