51

PACKAGED TERMINAL

COOLING UNIT WITH

HEAT PUMP OR ELECTRIC

HEATING
HVAC Guide Specifications

Size Range:

Cooling:

6,900 to 15,100 Btuh

Heating:

6,000 to 14,100 Btuh Heat Pump

6,400 to 17,000 Btuh Electric

Carrier Model Numbers:
52PC Premier Series, Cooling Only
52PE Premier Series, Cooling with Electric

Heat
52PQ Premier Series, Heat Pump with

Electric Heat
52CE Comfort Series, Cooling with Electric

Heat
52CQ Comfort Series, Heat Pump with

Electric Heat

Part 1 — General

1.01 SYSTEM DESCRIPTION

Single piece, thru-the-wall electrically controlled unit

using hermetic rotary compressor for cooling and heat

pump or electric resistance heat, as shown on the con-

tract drawings.
A. Insulated Polymer Wall Sleeve:

Wall sleeve shall provide excellent thermal insula-

tion, be textured to hide scratches and prevent

shine, will have superior outdoor noise absorption

and shall be corrosion free for the life of the prod-

uct. The wall sleeve must have dimensions of

42 in. width x 16 in. height x 14

7

/

8

in. depth and be

shipped with a rear weather barrier installed.

B. Wall Sleeve Molding:

Molding shall trim the wall sleeve to the existing

wall, to hide wall imperfections and irregularities in

the wall opening.

C. Outdoor Polymer Louvered Grille:

Outdoor grille shall resist corrosion, breakage and

match the color specified on drawing schedule and

specifications.

D. Subbase:

Subbase will support the wall sleeve when it

extends into the room more than 4 inches. Subbase

must come from the factory pre-assembled, with a

built in receptacle (size as specified on drawing

schedule and specifications) or with factory-

installed hardwire, pre-sized for an exact fit to the

unit.

1.02 QUALITY ASSURANCE

System shall be approved and certified by UL and

UL, Canada. Chassis capacity and efficiency perfor-

mance shall be certified in accordance with ARI

standard 310/380. Chassis shall meet ASHRAE

Standard 90.1 for minimum energy efficiency.
Chassis shall meet the New York City Department of

Building, Material and Equipment acceptance require-

ment (MEA).

1.03 DELIVERY, STORAGE, AND HANDLING

A. The packaging of the chassis shall be sufficient to

protect the chassis from damage during shipment

via an enclosed truck. Chassis must also be able to

withstand an impact force of 10 g and a random

continuous force of 1 g, during shipping.

B. Chassis, wall sleeves, and grilles shall be shipped in

separate cartons. Universal handling instructions

shall be defined and visible on the carton, from

front, back and sides.

C. Chassis shall be capable of withstanding tempera-

tures from –40 F to 155 F, at 5 to 95% RH, non-

condensing, during shipment and storage, without

component failure.

D. Unit shall be stored and handled per manufacturer’s

recommendations.

Part 2 — Products

2.01 EQUIPMENT

A. General:

Factory-assembled, single-piece heating and/or

cooling unit. Contained within the unit enclosure

shall be compressor, coils, fans and fan motor, heat-

ing means, controls, all wiring and piping, and a

full refrigerant charge (R-22).
Packaged Terminal Air Conditioners shall be of the

sizes and capacities as shown on the contract draw-

ing schedule and in the specifications.

B. Chassis:

The chassis shall be a factory-assembled, single-

piece heating and/or cooling unit, that is simple to

install and operate. Just slide the chassis into a wall

sleeve, plug it into an outlet, and operate after

installation. The chassis dimensions shall not

exceed 42 in. wide and 16 in. high with room cabi-

net in place. The chassis shall consist of the follow-

ing functional sections and components:

1. Operating Characteristics:

Chassis shall be capable of starting and run-

ning at 115 F ambient outdoor temperature per

maximum load criteria of ARI Standard 310/

380.

2. Electrical:

Chassis shall be equipped with a 58 in. power

cord for 208/230 v models or a 15 in. power

cord for 265 v models. The chassis current

draw shall be specified on the chassis name-

plate and match electrical requirements speci-

fied on the Contract drawing schedule and

specifications. The power cord plug configura-

tion shall conform to NEMA standards and the

rating shall support the current draw of the

electric resistance heater.
For 265 v installations, UL codes require the

use of an electrical equipped subbase for

power cord usage or hardwire conduit for non-

corded installations.

C. Airflow System:

The airflow system shall consist of one permanent

split-capacitor, direct-drive permanently lubri-

cated, two-speed fan motor for the indoor and out-

door fans. The outdoor fan shall be a dynamically

balanced, corrosion-resistant polymer multi-blade

GUIDE SPECIFICATIONS
