MINIMUM CLEARANCE FOR INDOOR AND
OUTDOOR DISCHARGE AIR
36" MINIMUM DISTANCE FROM
SLEEVE TO BUILDING WALLS,
SHRUBS, etc.
15” MINIMUM DISTANCE FROM
FRONT PANEL TO OBJECTS IN ROOM
2 3/8”
(60.3)
GRILLE
MOUNTING
HOLES
WALL SLEEVE-(2)
DRAIN LOCATIONS
CONDENSATE
OVERFLOW
HOLES
2 3/8”
(60.3)
OUTDOOR VIEW
(OUTSIDE)
WALL SLEEVE
GRILLE
MOUNTING
HOLES
52P and 52C Indoor and Outdoor Discharge Air Circulation
Blocking indoor or outdoor discharge air could
cause premature failure of unit.
Back of Polymer Wall Sleeve
DIMENSION DRAWINGS AND INSTALLATION
DATA — NEW CONSTRUCTION (cont)
