17
Insulated Metal Wall Sleeves
Part No.: SLEEVE-STEEL-1PK
Part No.: SLEEVE-EXT18-1PK
Part No.: SLEEVE-EXT24-1PK
Part No.: SLEEVE-EXT26-1PK
Part No.: SLEEVE-EXT28-1PK
Carrier's metal wall sleeves are available in a variety
of sizes for most applications and difficult installa-
tions. Choose from 14 in., 18 in., 24 in., 26 in., or
28 in. standard depth sizes. All metal wall sleeves
come with factory-installed insulation, designed to
minimize heat loss, reduce outdoor noise transmis-
sions into the room and prevent sleeve sweating. In
addition, the metal wall sleeve provides a flammability
rating higher than UL94-5V.
Wall Sleeve Molding Kit
Part No.: SLEEVE-MOLDING
For a superior look and to hide any construction
imperfections, use Carrier's wall sleeve molding kit to
trim the wall sleeve to the wall. The molding kit is a
perfect solution and can be used with any Carrier wall
sleeve (matches Carrier wall sleeve color).
Friedrich (and ZoneAire) Retro-
fit Wall Sleeve Adapter
Part No.: FR-SLEEVE-EXT
The Friedrich (and ZoneAire) wall sleeve adapter is
constructed of sheet metal and is designed to increase
the depth of an existing Friedrich T-series or ZoneAire
wall sleeve to accommodate Carrier’s industry stan-
dard PTAC units.
Climate Master Wall Sleeve
Adapter
Part No.: CM-SLEEVE-EXT
The Climate Master wall sleeve adapter is constructed
of sheet metal and is designed to increase the depth of
an existing Climate Master 12 1 /
2
in. wall sleeve to
accommodate Carrier’s industry standard PTAC units.
42 IN.
16 IN.
14/18/24/26/28 IN.
1/2 IN.
1 IN.
42 IN.
16 IN.
3 IN.
42 IN.
16 IN.
1 1/2 IN.
Standard and Extended Metal Wall Sleeve
Wall Sleeve Molding Kit
Friedrich Wall Sleeve Adapter Kit
Climate Master Wall Sleeve Adapter Kit
