Expanded ratings data (52p and 52c), Cooling performance – Carrier Packaged Terminal s & Heat Pumps 52P User Manual
Page 42
42
COOLING PERFORMANCE
ALL 7000 NOMINAL BTUH MODELS
Evaporator entering air temp. — 80 F Evap. air — 260 CFM
LEGEND
NOTES:
1. Total current (I) based on 230-volt system.
2. Evaporator entering dry bulb air temperature is 80 F.
ALL 9000 NOMINAL BTUH MODELS
Evaporator entering air temp. — 80 F Evap. air — 260 CFM
LEGEND
NOTES:
1. Total current (I) based on 230-volt system.
2. Evaporator entering dry bulb air temperature is 80 F.
52CQ 12,000 NOMINAL BTUH MODELS
Evaporator entering air temp. — 80 F Evap. air — 350 CFM
LEGEND
NOTES:
1. Total current (I) based on 230-volt system.
2. Evaporator entering dry bulb air temperature is 80 F.
52PC,PE,CE 12,000 NOMINAL BTUH MODELS
Evaporator entering air temp. — 80 F Evap. air — 350 CFM
LEGEND
NOTES:
1. Total current (I) based on 230-volt system.
2. Evaporator entering dry bulb air temperature is 80 F.
TEMP (F) AIR ENT.
COND (40% RH)
EVAP AIR — EWB (F)
57.00
62.00
67.00
72.00
80
MBtuh
7.05
7.23
8.04
8.85
kW
0.54
0.54
0.55
0.55
I
2.35
2.36
2.37
2.39
85
MBtuh
6.93
7.08
7.90
8.71
kW
0.56
0.57
0.57
0.57
I
2.45
2.46
2.48
2.49
90
MBtuh
6.85
6.95
7.72
8.54
kW
0.59
0.59
0.59
0.60
I
2.56
2.56
2.58
2.59
95
MBtuh
6.76
6.81
7.54
8.35
kW
0.61
0.61
0.62
0.62
I
2.67
2.67
2.68
2.89
100
MBtuh
6.70
6.70
7.36
8.17
kW
0.64
0.64
0.64
0.64
I
2.79
2.79
2.79
2.80
105
MBtuh
6.57
6.59
7.17
7.98
kW
0.67
0.67
0.67
0.67
I
2.91
2.91
2.91
2.92
110
MBtuh
6.42
6.41
6.97
7.79
kW
0.70
0.70
0.70
0.70
I
3.03
3.04
3.03
3.03
115
MBtuh
6.28
6.27
6.76
7.59
kW
0.73
0.73
0.72
0.73
I
3.17
3.17
3.17
3.16
EWB
—
Entering Wet Bulb
I
—
Compressor Current Amps
kW
—
Total Power
MBtuh
—
Total Cooling Capacity (Btuh in thousands)
RH
—
Relative Humidity
TEMP (F) AIR ENT.
COND (40% RH)
EVAP AIR — EWB (F)
57.00
62.00
67.00
72.00
80
MBtuh
8.58
8.91
9.71
10.46
kW
0.71
0.72
0.71
0.71
I
3.14
3.14
3.13
3.12
85
MBtuh
8.44
8.72
9.56
10.48
kW
0.75
0.75
0.74
0.74
I
3.28
3.28
3.27
3.27
90
MBtuh
8.29
8.52
9.47
10.39
kW
0.78
0.78
0.78
0.78
I
3.44
3.44
3.42
3.41
95
MBtuh
8.12
8.30
9.29
10.26
kW
0.82
0.82
0.81
0.81
I
3.59
3.60
3.58
3.56
100
MBtuh
7.94
8.07
9.06
10.07
kW
0.85
0.85
0.85
0.85
I
3.74
3.74
3.74
3.72
105
MBtuh
7.75
7.84
8.83
9.80
kW
0.89
0.89
0.89
0.88
I
3.89
3.90
3.92
3.89
110
MBtuh
7.57
7.60
8.59
9.67
kW
0.92
0.93
0.93
0.92
I
4.06
4.07
4.10
4.06
115
MBtuh
7.38
7.38
8.32
9.41
kW
0.96
0.97
0.97
0.97
I
4.24
4.24
4.27
4.24
EWB
—
Entering Wet Bulb
I
—
Compressor Current Amps
kW
—
Total Power
MBtuh
—
Total Cooling Capacity (Btuh in thousands)
RH
—
Relative Humidity
TEMP (F) AIR ENT.
COND (40% RH)
EVAP AIR — EWB (F)
57.00
62.00
67.00
72.00
80
MBtuh
12.44
12.74
13.61
13.84
kW
1.06
1.06
1.05
1.02
I
4.65
4.65
4.59
4.48
85
MBtuh
12.29
12.51
13.52
13.90
kW
1.10
1.10
1.09
1.07
I
4.85
4.84
4.80
4.69
90
MBtuh
12.10
12.29
13.20
13.84
kW
1.15
1.15
1.13
1.11
I
5.05
5.05
4.98
4.91
95
MBtuh
11.89
12.01
12.97
13.70
kW
1.20
1.20
1.18
1.17
I
5.26
5.26
5.18
5.12
100
MBtuh
11.66
11.73
12.72
13.34
kW
1.25
1.25
1.23
1.21
I
5.48
5.48
5.40
5.31
105
MBtuh
11.43
11.48
12.40
13.12
kW
1.30
1.30
1.28
1.26
I
5.70
5.70
5.62
5.52
110
MBtuh
11.19
11.23
12.20
12.98
kW
1.35
1.35
1.33
1.31
I
5.94
5.94
5.86
5.76
115
MBtuh
10.94
10.98
11.91
12.73
kW
1.41
1.41
1.39
1.37
I
6.18
6.18
6.10
6.00
EWB
—
Entering Wet Bulb
I
—
Compressor Current Amps
kW
—
Total Power
MBtuh
—
Total Cooling Capacity (Btuh in thousands)
RH
—
Relative Humidity
TEMP (F) AIR ENT.
COND (40% RH)
EVAP AIR — EWB (F)
57.00
62.00
67.00
72.00
80
MBtuh
12.17
12.50
12.83
13.23
kW
1.07
1.07
1.05
1.03
I
4.73
4.74
4.65
4.57
85
MBtuh
11.95
12.35
12.72
13.19
kW
1.11
1.11
1.10
1.08
I
4.93
4.95
4.86
4.79
90
MBtuh
11.74
12.10
12.62
13.06
kW
1.16
1.16
1.15
1.13
I
5.14
5.16
5.08
5.00
95
MBtuh
11.54
11.90
12.50
12.95
kW
1.21
1.21
1.20
1.17
I
5.36
5.38
5.31
5.21
100
MBtuh
11.37
11.68
12.35
12.80
kW
1.26
1.26
1.25
1.23
I
5.58
5.60
5.54
5.45
105
MBtuh
11.19
11.47
12.17
12.63
kW
1.31
1.31
1.30
1.28
I
5.81
5.83
5.78
5.68
110
MBtuh
11.04
11.28
11.93
12.44
kW
1.37
1.37
1.35
1.33
I
6.06
6.07
6.01
5.92
115
MBtuh
10.86
11.02
11.59
12.19
kW
1.42
1.42
1.41
1.39
I
6.31
6.31
6.25
6.17
EWB
—
Entering Wet Bulb
I
—
Compressor Current Amps
kW
—
Total Power
MBtuh
—
Total Cooling Capacity (Btuh in thousands)
RH
—
Relative Humidity
EXPANDED RATINGS DATA (52P AND 52C)
