37
PERFORMANCE AND ELECTRICAL DATA
MODEL 52PC AND PE (265-1-60)
52PC performance and electrical data is the same as 52PE without electric heat.
LEGEND
EER — Energy Efficiency Ratio
*Rated in accordance with ARI Standard 310-93.
†Electric resistance heater power and fan motor power.
**All 265-v units require an electrical subbase (receptacle or hard-
wire model).
RECEPTACLES AND FUSE TYPES
LEGEND
MODEL
NUMBER
52PE
CAPACITY* (Btuh)
HEATER
kW
EER
VOLTAGE
RANGE
(Volts)
AMPS WATTS
Cooling Heating Cooling Heating† Cooling Heating
007---4 7,200 — — 12.7
239-292
2.4 — 567 —
207---4 7,200 7,800 2.3 12.7 2.4 9.2 567 2396
307---4 7,200 11,600 3.4 12.7 2.4 13.3 567 3496
009---4 9,100 — — 11.7 3.0 — 778 —
209---4 9,100 7,800 2.3 11.7 3.0 9.2 778 2396
309---4 9,100 11,600 3.4 11.7 3.0 13.3 778 3496
012---4 12,100 — — 11.1 4.2 — 1090 —
212---4 12,100 7,800 2.3 11.1 4.2 9.4 1090 2470
312---4 12,100 11,600 3.4 11.1 4.2 13.5 1090 3570
512---4 12,100 17,000 5.0 11.1 4.2 19.6 1090 5170
015---4 15,100 — — 10.0 5.7 — 1510 —
215---4 15,100 7,800 2.3 10.0 5.7 9.4 1510 2470
315---4 15,100 11,600 3.4 10.0 5.7 13.5 1510 3570
515---4 15,100 17,000 5.0 10.0 5.7 19.6 1510 5170
MODEL
NUMBER
52PE
POWER
FACTOR
%
FAN MOTOR
MAX. FUSE
SIZE
(Amps)
MIN.
CIRCUIT
AMPS
RECEP-
TACLE
TYPE**
R-22
CHARGE
(oz)
DEHUMIDI-
FICATION
(Pints/Hr)
SENSIBLE
HEAT
FACTOR
APPROX.
CHASSIS
SHIP WT.
(lb)
Horsepower
Full
Load
Amps
Indoor
CFM
LO/HI
007---4
97 0.075 0.46 220/260
15 3.7 A
26 1.5 0.78 125 207---4 15 11.3 A
307---4 20 16.5 B
009---4
97 0.075 0.46 220/260
15 4.7 A
24 2.4 0.73 125 209---4 15 11.3 A
309---4 20 16.5 B
012---4
99 0.125 0.71 270/340
15 6.7 A
34 3.4 0.71 140
212---4 15 11.6 A
312---4 20 16.7 B
512---4 25 24.3 C
015---4
100 0.125 0.71 270/340
15 8.7 A
32 5.0 0.66 150
215---4 15 11.6 A
315---4 20 16.7 B
515---4 25 24.3 C
New York City Department of Buildings, Material and Equipment
Acceptance — MEA #242-04-E
UNIT NAMEPLATE VOLTAGE 265
OUTLET RATED VOLTS/AMPS 277/15 277/20 277/30
OUTLET BLADE CONFIGURATION
A B C
NEMA CONFIGURATION 7-15R 7-20R 7-30R
TIME DELAY FUSE OR HACR
CIRCUIT BREAKER (AMPS)
15 20 30
HEATER (KILOWATTS) 2.3 3.4 5.0
HACR — Heating, Air Conditioning, and Refrigeration
NEMA — National Electrical Manufacturers Association
