PERFORMANCE AND ELECTRICAL DATA
MODEL 52CE (265-1-60)
LEGEND
EER — Energy Efficiency Ratio
*Rated in accordance with ARI Standard 310-93.
†Electric resistance heater power and fan motor power.
**All 265-v units require an electrical subbase (receptacle or hard-
wire model).
RECEPTACLES AND FUSE TYPES
LEGEND
MODEL
NUMBER
52CE
CAPACITY* (Btuh)
HEATER
kW
EER
VOLTAGE
RANGE
(Volts)
AMPS WATTS
Cooling Heating Cooling Heating† Cooling Heating
207---4 7,000 7,800 2.3 11.1
239-292
2.7 9.2 631 2396
307---4 7,000 11,600 3.4 11.1 2.7 13.3 631 3496
209---4 8,900 7,800 2.3 10.7 3.4 9.2 832 2396
309---4 8,900 11,600 3.4 10.7 3.4 13.3 832 3496
212---4 12,000 7,800 2.3 10.1 4.7 9.4 1188 2470
312---4 12,000 11,600 3.4 10.1 4.7 13.5 1188 3570
512---4 12,000 17,000 5.0 10.1 4.7 19.6 1188 5170
215---4 14,600 7,800 2.3 9.5 5.7 9.4 1537 2470
315---4 14,600 11,600 3.4 9.5 5.7 13.5 1537 3570
515---4 14,600 17,000 5.0 9.5 5.7 19.6 1537 5170
MODEL
NUMBER
52CE
POWER
FACTOR
%
FAN MOTOR
MAX. FUSE
SIZE
(Amps)
MIN.
CIRCUIT
AMPS
RECEP-
TACLE
TYPE**
R-22
CHARGE
(oz)
DEHUMIDI-
FICATION
(Pints/Hr)
SENSIBLE
HEAT
FACTOR
APPROX.
CHASSIS
SHIP WT
(lb)
Horsepower
Full
Load
Amps
Indoor
CFM
LO/HI
207---4
97 0.075 0.46 220/260
15 11.3 A
22 1.5 0.78 125
307---4 20 16.5 B
209---4
97 0.075 0.46 220/260
15 11.3 A
29 2.4 0.73 125
309---4 20 16.5 B
212---4
99 0.125 0.71 270/340
15 11.6 A
28 3.4 0.71 140 312---4 20 16.7 B
512---4 25 24.3 C
215---4
100 0.125 0.71 270/340
15 11.6 A
32 5.0 0.66 150 315---4 20 16.7 B
515---4 25 24.3 C
New York City Department of Buildings, Material and Equipment
Acceptance — MEA #242-04-E
UNIT NAMEPLATE VOLTAGE 265
OUTLET RATED VOLTS/AMPS 277/15 277/20 277/30
OUTLET BLADE CONFIGURATION
A B C
NEMA CONFIGURATION 7-15R 7-20R 7-30R
TIME DELAY FUSE OR HACR
CIRCUIT BREAKER (AMPS)
15 20 30
HEATER (KILOWATTS) 2.3 3.4 5.0
HACR — Heating, Air Conditioning, and Refrigeration
NEMA — National Electrical Manufacturers Association
