36
PERFORMANCE AND ELECTRICAL DATA
MODEL 52PC AND PE (230/208-1-60)
52PC performance and electrical data is the same as 52PE without electric heat.
LEGEND
EER — Energy Efficiency Ratio
*Rated in accordance with ARI Standard 310-93.
†Electric resistance heater power and fan motor power.
**Fan motor indoor CFM (LO/HI) shown for 230-1-60 units.
RECEPTACLES AND FUSE TYPES
LEGEND
*May be used for 15-amp applications if fused for 15 amps.
MODEL
NUMBER
52PE
CAPACITY* (Btuh)
HEATER
kW
EER
VOLTAGE
RANGE
(Volts)
AMPS WATTS
Cooling Heating Cooling Heating† Cooling Heating
007---3 7,200/ 7,100 — — 12.7/12.7
187-253
2.7/2.9 — 567/ 559 —
207---3 7,200/ 7,100 7,800/ 6,400 2.3 12.7/12.7 2.7/2.9 10.4/ 9.5 567/ 559 2393/1985
307---3 7,200/ 7,100 11,600/ 9,700 3.4 12.7/12.7 2.7/2.9 15.2/14.1 567/ 559 3493/2935
009---3 9,100/ 9,000 — — 11.7/11.9 3.0/3.1 — 778/ 756 —
209---3 9,100/ 9,000 7,800/ 6,400 2.3 11.7/11.9 3.0/3.1 10.4/ 9.5 778/ 756 2393/1985
309---3 9,100/ 9,000 11,600/ 9,700 3.4 11.7/11.9 3.0/3.1 15.2/14.1 778/ 756 3493/2935
012---3 12,100/12,000 — — 11.1/10.7 4.8/5.3 — 1090/1122 —
212---3 12,100/12,000 7,800/ 6,400 2.3 11.1/10.7 4.8/5.3 10.8/ 9.9 1090/1122 2470/2047
312---3 12,100/12,000 11,600/ 9,700 3.4 11.1/10.7 4.8/5.3 15.6/14.5 1090/1122 3570/2997
512---3 12,100/12,000 17,000/13,600 5.0 11.1/10.7 4.8/5.3 22.5/20.0 1090/1122 5170/4147
015---3 15,000/14,700 — — 9.8/ 9.8 6.4/7.1 — 1531/1500 —
215---3 15,000/14,700 7,800/ 6,400 2.3 9.8/ 9.8 6.4/7.1 10.8/ 9.8 1531/1500 2470/2047
315---3 15,000/14,700 11,600/ 9,700 3.4 9.8/ 9.8 6.4/7.1 15.6/14.5 1531/1500 3570/2997
515---3 15,000/14,700 17,000/13,600 5.0 9.8/ 9.8 6.4/7.1 22.5/20.0 1531/1500 5170/4147
MODEL
NUMBER
52PE
POWER
FACTOR
(%)
FAN MOTOR MAX.
FUSE
SIZE
(Amps)
MIN.
CIRCUIT
AMPS
RECEP-
TACLE
TYPE
R-22
CHARGE
(oz)
DEHUMIDIFI-
CATION
(Pints/Hr)
SENSIBLE
HEAT
FACTOR
APPROX.
SHIP WT.
(lb)
Horsepower
Full
Load
Amps
Indoor
CFM
LO/HI**
007---3
100 0.075 0.44 220/260
15 4.8 A
24 1.5 0.78 125 207---3 15 13.0 A
307---3 20 19.0 B
009---3
99 0.075 0.44 220/260
15 5.4 A
23 2.4 0.73 125 209---3 15 13.0 A
309---3 20 19.0 B
012---3
99 0.125 0.75 270/350
15 8.4 A
34 3.4 0.71 140
212---3 15 13.3 A
312---3 20 19.3 B
512---3 30 27.9 C
015---3
95 0.125 0.75 270/350
15 11.1 A
32 4.8 0.66 150
215---3 15 13.3 A
315---3 20 19.3 B
515---3 30 27.9 C
New York City Department of Buildings, Material and Equipment
Acceptance — MEA #242-04-E
UNIT NAMEPLATE VOLTAGE 230/208
OUTLET RATED VOLTS/AMPS 250/15 250/20 250/30
OUTLET BLADE CONFIGURATION
A B C
TIME DELAY FUSE OR HACR CIRCUIT BREAKER (AMPS) 15 20* 30
HEATER (KILOWATTS) 2.3 3.4 5.0
HACR — Heating, Air Conditioning, and Refrigeration
NEMA — National Electrical Manufacturers Association
PRODUCT DATA (52P) (cont)
