Nomenclature
Control Unit
< MODE > flash mode button--------
• Loops in the following sequence:
r—^ ETTL/TTL-------- ►M -------
*<- LCD panel illumination-----
button (^p.19)
button(->p.64)
< O > button -
Focusing iamp button(->p.20)
< PILOT >-
Pilot lamp (-^p.16)
Test firing button (^p.16)
• Uniform modeiing fiash
Hp.55)
• SE cancei (->p.15,44)
Locking coiiar (^p.13)
Fiash exposure confirmation iamp
Hp.16)
< D> > button
< itH > High-speed sync
(FP fiash) button (^p.36)
(^p.40, 62)
When these two buttons are
pressed simultaneously, the setting
changes in the following loop:
-----► H»-------
(OFF)^------------
*<-!-> Increment button
*< — > Decrement button
*
Select/Set button
Channel button
(^p.42)
Main switch (->p.15)
Flash ratio control / Flash tube
switching button
Hp.26, 39, 42, 54, 61)
Q Asterisked items have functions which remain effective for (^8) after the button
Is released. The <-§-> button Illuminates the LCD panel for (^12).
