Setting Up a Wireless Flash System
By using a Speedlite 550EX as a slave unit, you can set up a wireless flash
system with the MR-14EX.
Setting the MR-14EX as the Master Unit
As with the Speedlite 550EX, the MR-14EX can be set as the master unit
which transmits wireless signals to the slave unit.
1
Press the MR-14EX’s
button and select
ettl
.
► Pressing the
toggles the flash mode between
ETTL and M.
-► ETTL---- ► M —
Press the
<
ratio
>
button and
select
uhMM
a
:
b
c
.
► Each time you press the button, the
selection will change in the following
loop:
B
A : B C <
I
--- ►(OFF)
------
► lifAliLO A
:
I
I------^— EEBBl A : B C ◄-
will be displayed.
Press the
the channel.
• Select a channel from 1 to 4.
O Be sure to set the same channel No. for the master and slave unit. Otherwise,
slave C will not fire.
42
