Replacing the Heatsink Assembly
1.
Align the four captive screws on the heatsink assembly with the screw holes on the system board and secure the screws. Tighten the four numbered
screws in sequential order.
2.
Replace the system board assembly (see
Removing the System Board Assembly
).
3.
Replace the DC power cable (see
Replacing the DC Power Cable
).
4.
Replace the palm rest assembly (
Replacing the Palm Rest Assembly
).
5.
Replace the coin-cell battery (see
Replacing the Coin-Cell Battery
).
6.
Replace the display assembly (see
Replacing the Display Assembly
).
7.
Replace the module with Bluetooth wireless technology (see
Replacing the Card With Bluetooth Wireless Technology
).
8.
Replace the keyboard (see
Replacing the Keyboard
).
9.
Replace the LED cover (see
Replacing the LED Cover
).
10.
Replace the solid state drive (see
Replacing the Solid State Drive and Cable Assembly
).
11.
Replace the memory module (see
Replacing the Memory Module
).
12.
Replace the WLAN and WWAN cards (see
Replacing the WLAN/WiMax Card
and
Replacing a WWAN Card
).
13.
Replace the service panel (see
Replacing the Service Panel
).
14.
Follow the procedures in
After Working on Your Computer
.
Back to Contents Page
CAUTION:
Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage on www.dell.com at: www.dell.com/regulatory_compliance.
