When the processor is fully seated in the socket, rotate the socket release lever back down until it snaps into place, securing the processor.
12. Install the heat sink.
a. Using a clean lint-free cloth, remove the existing thermal grease from the heat sink.
b. Apply thermal grease evenly to the top of the processor.
c. Align the holes on both sides of the heat sink with the heat-sink posts on the system chassis. See Figure 6 -13 .
13. Orient the securing clips so that the rubber-coated tabs are toward the back of the chassis.
14. Lower the end opposite of the rubber-coated tab of each securing clip over the heat-sink post, and then slide the securing clip toward the heat-sink
post. See Figure 6 -13 .
15. While holding down the rubber-coated tab with one hand, push the latch on the securing clip toward the heat-sink post until it locks the clip onto the
post.
16. Repeat step 14 and step 15 for the other securing clip.
17. Install the cooling shroud. See " Installing the Cooling Shroud ."
18. Close the system. See " Closing the System " in "Troubleshooting Your System."
As the system boots, it detects the presence of the new processor and automatically changes the system configuration information in the System Setup
program.
19. Press to enter the System Setup program, and check that the processor information matches the new system configuration.
See your User's Guide for instructions about using the System Setup program.
20. Run the system diagnostics to verify that the new processor operates correctly.
See " Running the System Diagnostics " for information about running the diagnostics and troubleshooting processor problems.
Back to Contents Page
NOTE: Use the heat sink that you removed in step 6 .
NOTE: If the securing clips are installed so that the rubber-coated tabs are toward the front of the system, the cooling shroud cannot be installed
correctly.
