2. Open the system. See " Opening the System ."
3. Ensure that the processor and heat sink are properly installed. See " Replacing the Processor " in "Installing System Options."
4. Close the system. See " Closing the System ."
5. Run Quick Tests in the system diagnostics. See " Running the System Diagnostics ."
If the test fails, continue to the next step.
6. Open the system. See " Opening the System ."
7. Replace the processor. See " Replacing the Processor ."
8. Close the system. See " Closing the System ."
9. Run Quick Tests in the system diagnostics. See " Running the System Diagnostics ."
If the tests fail or the problem persists, see " Getting Help ."
Troubleshooting the System Board
Problem
l Error message indicates a system board problem.
Action
1. Open the system. See " Opening the System ."
2. Remove the expansion cards, if installed. See " Installing and Removing a CERC SATA RAID Controller " in "Installing System Components."
3. Close the system. See " Closing the System ."
4. Run the system board tests in the system diagnostics. See " Running the System Diagnostics ."
If the tests do not run successfully, see " Getting Help ."
5. Open the system. See " Opening the System ."
6. Reinstall the one of the expansion cards that you removed in step 2 . See " Installing an Expansion Card " in "Installing System Components."
7. Close the system. See " Closing the System ."
8. Run the system board tests again.
If the tests do not complete successfully, the expansion card might be faulty. See " Getting Help ."
If the tests complete successfully, repeat step 5 through step 8 for the remaining expansion card, if applicable.
