System Board Information

355

PowerEdge M605 System Board

Figure 7-12. PowerEdge M605 System Board Connectors

Connector

Description

1 Data 2

Data cable connector 2

2 -

Mezzanine interface card connectors

3 Data 1

Data cable connector 1

Table 7-18. PowerEdge M605 System Board Connectors

Connector

Description

1

-

Mezzanine card connector - Fabric C

2

-

Mezzanine card connector - Fabric B

3 A1

Memory module connector, slot A1

4 A2

Memory module connector, slot A2

5 A3

Memory module connector, slot A3

6 A4

Memory module connector, slot A4

7 CPU1

Processor 1 socket

2

1

3

4

5

6

7

8

9

10

11

12

14

15

16

17

13

18
