292

Installing Enclosure Components

Figure 4-3. Removing and Installing a Fan Module

Installing a Fan Module

1 Inspect the fan for debris before installing the fan in the enclosure.
2 Slide the fan module into the enclosure until it is fully seated and the

release button engages. See Figure 4-3.

1

fan module

2

release button

1

2
