PowerEdge M710HD Jumper Settings

Figure 7-6 shows the location of the configuration jumpers on the blade

system board. Table 7-6 lists the jumper settings.

NOTE:

Figure 7-6 is oriented with the front end of the blade system board facing to

the right.

Table 7-6. PowerEdge M710HD Jumper Settings

PSWD_EN

(default) The password feature is enabled.

The password feature is disabled.

NVRAM_CLR

(default) The configuration settings are retained at

system boot.

The configuration settings are cleared at the

next system boot. (If the configuration settings

become corrupted to the point where the

system does not boot, install the jumper and

boot the system. Remove the jumper before

restoring the configuration information.)
