350 System Board Information
PowerEdge M610x System Board
Figure 7-8. PowerEdge M610x System Board Connectors
9 - Hard-drive backplane connector
10 B1 – B6 Memory modules B1 – B6
11 - RAID battery connector
12 CPU1 Processor 1 socket
13 - iDRAC6 enterprise card connector
Table 7-15. PowerEdge M610 System Board Connectors (continued)
Connector Description
3
7 13
1 2 4
12 9 11 8 6
5
10
