220

Installing Blade Components

Figure 3-24. Installing and Removing a Mezzanine Card - Full-Height Blades

1

optional Fabric C mezzanine card 1

2

optional Fabric B mezzanine card 2

3

optional Fabric C mezzanine card 3

4

optional Fabric B mezzanine card 4

5

retention latch

6

mezzanine card connector

7

mezzanine card

5

1

2

3

4

6

7
