340 System Board Information
PowerEdge M910 System Board
Figure 7-2. PowerEdge M910 System Board Connectors
Table 7-10. PowerEdge M910 System Board Connectors
Connector Description
1 J_INT_USB USB connector
2 CPU2 Processor 2 socket
3 CPU4 Processor 4 socket
4 B1 – B8 Memory modules B1 – B8
5 - Optional RAID battery
17
18
3 4
7
10
14
15
16
9
12
11
6
2
20
8
19
13
1 5
