164 Installing Blade Components
Figure 3-6. Inside a Half-Height Blade (PowerEdge M610)
1 optional mezzanine card
Mezz3_Fab_C
2 optional mezzanine card -
Mezz4_Fab_B
3 memory modules 4 processor CPU2 and heat sink
5 hard-drive backplane 6 storage controller card (under
drive bays)
7 hard drive 1 8 hard drive 0
9 processor CPU1 and heat sink 10 iDRAC6 Enterprise card (under
mezzanine card
2
3
4
5
1
7
8
9
6
10
