162 Installing Blade Components
Inside the System
Figure 3-4 through Figure 3-12 show the interior components in the blades.
Figure 3-4. Inside a Half-Height Blade (PowerEdge M710HD)
1 iDRAC6 enterprise card 2 optional mezzanine card 1 -
Fabric C
3 optional mezzanine card 2 -
Fabric B
4 network daughter card
5 memory modules (A1 to A9) 6 processor CPU2 and heat sink
7 hard drives (2) 8 hard-drive backplane
9 memory modules (B1 to B9) 10 processor CPU1 and heat sink
1
6
7
9
2 3 4
8
5
10
